This 2023 Carryall 700 Electric HP is the ultimate workhorse. With its 48V AC electric powertrain, this rugged utility vehicle boasts impressive performance, power, and acceleration for any task. Plus, it's equipped with a differential guard, heavy-duty brush guard, electric bed lift, onboard high-frequency charger, single-point battery watering system, and extra heavy-duty front suspension. Enjoy ultimate convenience with built-in USB ports, rear lighting, turn signals, a horn, and a battery level indicator.
Power
- Engine/Motor Type: 48v AC
- Controller: 400 Amp - Solid State
- Horsepower (rated): 8.0 HP (6.0 kW), Peak 16.0 HP (11.7 kW)
- Transmission: Direct Drive, Double Reduction Helical Gear
- Gear Selection: Forward/Neutral/Reverse
- Gear Ratio: 12.32:1
- Battery: Eight (8) - 6v Flooded Lead Acid
- Charger: Delta-Q Quiq (1kW High Frequency)
- Top Speed: 5-17 mph
Steering & Suspension
- Steering Mechanism: Self-adjusting Rack and Pinion
- Suspension: Independent Leaf Spring w/ Dual Hydraulic Shocks
Brakes
- Brakes: 4-Wheel Mechanical Drum
- Park Brake: Foot Operated, Multi-lock
Body & Tires
- Headlights: Two (2) 37.5w Halogen
- Body - Front and Finish: ArmorFlex® w/ Automotive Paint/Clearcoat
- Body - Rear: Aluminum
- Tires: 20 x 10-10, 6-ply, Premium Tread
Dimensions & Weights
- Overall Height: 47.1"
- Overall Length: 137.5"
- Max Width (w/o Mirrors): 50.3"
- Ground Clearance (Differential): 5.6"
- Vehicle Weight: 1,475 lbs.
- Bed Length x Width x Height (Cargo Box): 65.5" x 47.5" x 10.5"
- Bed Load Capacity: 1,000 lbs.
- Total Vehicle Capacity: 1,500 lbs.
- Towing Capacity: 1,500 lbs.
- Wheelbase: 99.1"
- Track Width (Front): 36.6"
- Track Width (Rear): 39.5"
Warranty
- 4-Year - Limited Battery Warranty
- 3-Year - Limited Powertrain and Frame
- 2-Year - Limited Remaining Vehicle
